Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications4 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Variant / construction | Adapter sleeves | |
| Bore diameter | d | 670 mm |
| Width | B | 467 mm |
| Mass | ≈m | 392 kg |
Dimensions3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore diameter | 670.0 mm | |
| Width | 467.0 mm | |
| Thread designation | Tr 710x7 |
Product identity5 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Official product category | Adapter sleeves | |
| Official taxonomy path | /products/rolling-bearings/accessories/adapter-sleeves | |
| Structure group ID | ASA_001 | |
| Available from SKF | Yes | |
| Remanufacturable | No |
Engineering — Associated products1 parameter
| Parameter | Symbol | Value |
|---|---|---|
| Hydraulic nut | HMV 142E |
Engineering — Dimensions11 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore diameter | d 1 | 670 mm |
| Outside diameter small taper | d | 710 mm |
| Outside diameter lock nut | d 3 | 900 mm |
| Width | B 1 | 467 mm |
| Width lock nut | B | 106 mm |
| Width lock nut including locking clip | B 5 | 135 mm |
| Thread | G | Tr 710x7 |
| Thread oil supply duct | G 2 | G 1/8 |
| Length thread for oil supply duct | G 3 | 12 mm |
| Distance bore - oil supply duct | A | 8 mm |
| External taper | 1:12 |
Engineering — Included products2 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Lock nut | HME 31/710 | |
| Locking device | MS 31/710 |
Logistics3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Product net weight | 392.0 kg | |
| eClass code | 23-11-07-05 | |
| UNSPSC code | 31163218 |
Properties2 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Taper | 1:12 | |
| Holes for oil injection | With |
