SKF BLRB 365216 A-2RS Radial spherical plain bearing, customized design MANUFACTURER PRODUCT VIEW
SKF / Radial spherical plain bearings

SKF BLRB 365216 A-2RS

Radial spherical plain bearing, customized design technical reference with manufacturer-sourced dimensions, characteristics and engineering resources.

Technical data available
Bore diameterd
60 mm
Outside diameterD
100 mm
Mass≈m
2.16 kg
Bore diameter
60.0 mm
Outside diameter
100.0 mm
Width, inner ring
72.0 mm
Compare this model by brand →Check interchange requirements →

Use this page as a technical reference. Verify the current manufacturer specification and the complete application requirements before selection.

Technical data

Product specifications

Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.

Core specifications5 parameters
Core specifications
ParameterSymbolValue
Variant / constructionRadial spherical plain bearings
Bore diameterd60 mm
Outside diameterD100 mm
Mass≈m2.16 kg
SealingSeal on both sides
Dimensions4 parameters
Dimensions
ParameterSymbolValue
Bore diameter60.0 mm
Outside diameter100.0 mm
Width, inner ring72.0 mm
Width, outer ring56.0 mm
Product identity4 parameters
Product identity
ParameterSymbolValue
Official product categoryRadial spherical plain bearings
Official taxonomy path/products/plain-bearings/spherical-plain-bearings-rod-ends/radial
Available from SKFYes
RemanufacturableNo
Logistics3 parameters
Logistics
ParameterSymbolValue
Product net weight2.16 kg
eClass code23-05-01-06
UNSPSC code31171515
Properties3 parameters
Properties
ParameterSymbolValue
SealingSeal on both sides
Sealing typeSpecial seal
Relubrication featureWithout

Technical documents & data sheet

This product page is a BearingScope catalogue reference, not a manufacturer-certified drawing. Preserve the full brand and designation when comparing files.

Record identity
SKF BLRB 365216 A-2RS
Document matching
Exact designation, assembly scope, revision and units must agree.

No verified redistributable CAD or manufacturer PDF is registered for this exact model. A catalogue image is not a dimensioned drawing. Missing technical files are not generated or replaced with unrelated models.
