Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications11 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Variant / construction | Spherical roller thrust bearings | |
| Bore diameter | d | 750 mm |
| Outside diameter | D | 1280 mm |
| Height | H | 315 mm |
| Basic dynamic load rating | C | 18700 kN |
| Basic static load rating | C0 | 85000 kN |
| Fatigue load limit | Pu | 5500 kN |
| Reference speed | nref | 200 r/min |
| Limiting speed | nG | 400 r/min |
| Mass | ≈m | 1644 kg |
| Cage | Machined brass |
Dimensions3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore diameter | 750.0 mm | |
| Outside diameter | 1280.0 mm | |
| Height | 315.0 mm |
Product identity5 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Official product category | Spherical roller thrust bearings | |
| Official taxonomy path | /products/rolling-bearings/roller-bearings/spherical-roller-thrust-bearings | |
| Structure group ID | BHS_001 | |
| Available from SKF | Yes | |
| Remanufacturable | Yes |
Engineering — Abutment dimensions3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Diameter of shaft abutment | d a | min. 1015 mm |
| Diameter of housing abutment | D a | max. 1120 mm |
| Fillet radius | r a | max. 12 mm |
Engineering — Calculation data6 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Basic dynamic load rating | C | 18700 kN |
| Basic static load rating | C 0 | 85000 kN |
| Fatigue load limit | P u | 5500 kN |
| Reference speed | 200 r/min | |
| Limiting speed | 400 r/min | |
| Minimum axial load factor | A | 690 |
Engineering — Dimensions10 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore diameter | d | 750 mm |
| Outside diameter | D | 1280 mm |
| Height | H | 315 mm |
| Outside diameter of shaft washer end side face | d 1 | ≈ 1170 mm |
| Shoulder diameter outer ring | D 1 | ≈ 964 mm |
| Width shaft washer or length of shaft washer bore diameter that fits on shaft (bearings with a machined cage) | B | 121 mm |
| Height shaft washer + cage | B 1 | 305 mm |
| Height housing washer | C | 153 mm |
| Distance from shaft washer end side face to pressure point | s | 436 mm |
| Chamfer dimension shaft washer | r 1,2 | min. 15 mm |
Logistics3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Product net weight | 1644.0 kg | |
| eClass code | 23-05-09-11 | |
| UNSPSC code | 31171507 |
Performance4 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Basic dynamic load rating | 18700.0 kN | |
| Basic static load rating | 85000.0 kN | |
| Reference speed | 200.0 r/min | |
| Limiting speed | 400.0 r/min |
Properties7 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Locating feature, housing washer | None | |
| Bore type | Cylindrical | |
| Cage | Machined brass | |
| Tolerance class | Normal | |
| Candidate for remanufacturing | Yes | |
| Indicative carbon footprint for new product | 6083.0 kg CO 2 e | |
| Indicative carbon footprint for remanufactured product | 2022.0 kg CO 2 e |
