Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications8 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore diameter | d | 55 mm |
| Outside diameter | D | 100 mm |
| Width | B | 55.5 mm |
| Basic dynamic load rating | C | 46 kN |
| Basic static load rating | C0 | 29 kN |
| Mass | ≈m | 1.35 kg |
| Minimum operating temperature | Tmin | -20 °C |
| Maximum operating temperature | Tmax | 120 °C |
Main Dimensions & Performance Data7 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore diameter | d | 55 mm2.165 in |
| Outside diameter | DSP | 100 mm3.937 in |
| Width | B | 55.5 mm2.185 in |
| Basic static load rating, radial | C0r | 29,000 N6,519.784 lbf |
| Locking collar total width | B1 | 71.4 mm2.811 in |
| Basic dynamic load rating, radial | Cr | 46,000 N10,341.727 lbf |
| Mass | ≈m | 1.35 kg2.976 lbs |
Dimensions7 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Width, outer ring | C | 25 mm0.984 in |
| Sealing total width | C2 | 25.42 mm1.001 in |
| Distance raceway | S | 27.8 mm1.094 in |
| Rib diameter inner ring | d1 | 69.77 mm2.747 in |
| Distance to lubrication hole | Ca | 7 mm0.276 in |
| Outside diameter locking collar/locknut | d3 | 76 mm2.992 in |
| Width of flats | W | 5 mm0.197 in |
Temperature range2 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Operating temperature min. | Tmin | -20 °C-4 °F |
| Operating temperature max. | Tmax | 120 °C248 °F |
Capabilities & suitability7 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Radial load capacity | Yes | |
| Axial load capacity in one direction | Yes | |
| Axial load capacity in both directions | Yes | |
| Lifetimelubricationfreedomfrommaintenance | Yes | |
| Suitable for grease lubrication | Yes | |
| Sealedonbothsides | Yes | |
| Staticangularerrorandmisalignment | Yes |
Manufacturer Identity6 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Schaeffler Product Code | 4107811 | |
| Brand | FAG | |
| Base Type | UEL211 | |
| SAP material number | 3053266510000 | |
| Base product | 2305080204 | |
| Mounting Manager ID | UEL211 |
Product Identity2 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Construction | Radial insert ball bearing UEL, spherical outer ring, location by eccentric locking collar, RSR seal on both sides | |
| Short Description | Radial insert ball bearing |
Technical Data15 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore Diameter (D) | 55 mm | |
| Outside Diameter (Dsp) | 100 mm | |
| Total Width (B) | 55.5 mm | |
| Basic Dynamic Load Rating, Radial (Cr) | 46,000 N | |
| Basic Static Load Rating, Radial (C0R) | 29,000 N | |
| Operating Temperature Min. (Tmin) | -20 °C | |
| Locking Collar Total Width (B1) | 71.4 mm | |
| Operating Temperature Max. (Tmax) | 120 °C | |
| Distance To Lubrication Hole (Ca) | 7 mm | |
| Width Of Flats (W) | 5 mm | |
| Width, Outer Ring (C) | 25 mm | |
| Rib Diameter Inner Ring (D1) | 69.77 mm | |
| Sealing Total Width (C2) | 25.42 mm | |
| Outside Diameter Locking Collar/Locknut (D3) | 76 mm | |
| Distance Raceway (S) | 27.8 mm |
