FAG BTAC64

Sealing rings technical reference with manufacturer-sourced dimensions, characteristics and engineering resources.

Technical data available

Outside diameterD: 445 mm
WidthB: 41 mm
Mass≈m: 22.8 kg
Shaft diameterd: 304 mm / 11.969 in
Overhang outsideg: 41 mm / 1.614 in
Outside diameterda: 445 mm / 17.52 in

Compare this model by brand →Check interchange requirements →

Use this page as a technical reference. Verify the current manufacturer specification and the complete application requirements before selection.

Technical data

Product specifications

Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.

Core specifications3 parameters

Core specifications
Parameter	Symbol	Value
Outside diameter	D	445 mm
Width	B	41 mm
Mass	≈m	22.8 kg

Main Dimensions & Performance Data6 parameters

Main Dimensions & Performance Data
Parameter	Symbol	Value
Shaft diameter	d	304 mm11.969 in
Width	b	71 mm2.795 in
Overhang outside	g	41 mm1.614 in
Outside diameter	da	445 mm17.52 in
Centering Diameter	dc	416 mm16.378 in
Mass	≈m	22.8 kg50.265 lbs

Manufacturer Identity4 parameters

Manufacturer Identity
Parameter	Symbol	Value
Schaeffler Product Code		1284246
Brand		FAG
SAP material number		0864289690000
Base product		2307170207_NoSuffix

Product Identity2 parameters

Product Identity
Parameter	Symbol	Value
Construction		Bolt-on seals BTAC, for SNS-housing, attached
Short Description		Sealing ring

Technical Data2 parameters

Technical Data
Parameter	Symbol	Value
Width (B)		41 mm
Outside Diameter (D)		445 mm

Technical documents & data sheet

This product page is a BearingScope catalogue reference, not a manufacturer-certified drawing. Preserve the full brand and designation when comparing files.

Record identity: FAG BTAC64
Document matching: Exact designation, assembly scope, revision and units must agree.

No verified redistributable CAD or manufacturer PDF is registered for this exact model. A catalogue image is not a dimensioned drawing. Missing technical files are not generated or replaced with unrelated models.
