Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications10 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore diameter | d | 130 mm |
| Outside diameter | D | 170 mm |
| Width | B | 30 mm |
| Reference speed | nref | 2490 r/min |
| Limiting speed | nG | 2850 r/min |
| Mass | ≈m | 1.757 kg |
| Precision class | PN — Normal (ISO 492:2023) | |
| Cage | JP — Steel sheet metal | |
| Minimum operating temperature | Tmin | -30 °C |
| Maximum operating temperature | Tmax | 150 °C |
Product characteristics3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Cage | JP | Steel sheet metal |
| Tolerance class | PN | Normal (ISO 492:2023) |
| Dimensional / heat stabilization | S0 | Rings dimensional stabilized up to 150° |
Main Dimensions & Performance Data9 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Inner diameter shaft washer | d | 130 mm5.118 in |
| Outer diameter housing washer | D | 170 mm6.693 in |
| Height | T | 30 mm1.181 in |
| Basic dynamic load rating, axial | Ca | 111,000 N24,955.036 lbf |
| Basic static load rating, axial | C0a | 390,000 N87,679.856 lbf |
| Fatigue load limit, axial | Cua | 14,600 N3,282.374 lbf |
| Limiting speed | nG | 2,850 1/min |
| Reference speed | nϑr | 2,490 1/min |
| Mass | ≈m | 1.757 kg3.874 lbs |
Mounting dimensions3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Minimum diameter shaft shoulder | da min | 154 mm6.063 in |
| Maximum diameter of housing shoulder | Da max | 146 mm5.748 in |
| Maximum filled radius | ra max | 1 mm0.039 in |
Dimensions3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Minimum chamfer dimension | rmin | 1 mm0.039 in |
| Inner diameter housing washer | D1 | 132 mm5.197 in |
| Outer diameter shaft washer | d1 | 170 mm6.693 in |
Temperature range2 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Operating temperature min. | Tmin | -30 °C-22 °F |
| Operating temperature max. | Tmax | 150 °C302 °F |
Calculation factors1 parameter
| Parameter | Symbol | Value |
|---|---|---|
| Minimum load factor | A | 0.76 |
Capabilities & suitability4 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Axial load capacity in one direction | Yes | |
| Suitable for grease lubrication | Yes | |
| Suitable for oil lubrication | Yes | |
| Unsealed design | Yes |
Manufacturer Identity9 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Schaeffler Product Code | 394444 | |
| Brand | FAG | |
| Base Type | 51126 | |
| X Life Marking | n.r. | |
| SAP material number | 0167148650000 | |
| Base product | 2305100101 | |
| Bearing X designation | 51126 | |
| Mounting Manager ID | 51126 | |
| Grease application ID | 51126 |
Product Identity2 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Construction | Axial deep groove ball bearing 511, single direction, steel sheet metal cage | |
| Short Description | Axial deep groove ball bearing |
Technical Data17 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore Diameter (D) | 130 mm | |
| Outside Diameter (D) | 170 mm | |
| Width (B) | 30 mm | |
| Basic Dynamic Load Rating, Axial (Ca) | 111,000 N | |
| Basic Static Load Rating, Axial (C0A) | 390,000 N | |
| Operating Temperature Min. (Tmin) | -30 °C | |
| Limiting Speed (Ng) | 2,850 1/min | |
| Operating Temperature Max. (Tmax) | 150 °C | |
| Reference Speed (Nϑr) | 2,490 1/min | |
| Minimum Diameter Shaft Shoulder (Da Min) | 154 mm | |
| Minimum Load Factor (A) | 0.76 | |
| Rip Diameter Shaft Washer (D1) | 170 mm | |
| Bore Diameter Housing Washer (D1) | 132 mm | |
| Maximum Diameter Of Housing Shoulder (Da Max) | 146 mm | |
| Minimum Chamfer Dimension (Rmin) | 1 mm | |
| Maximum Fillet Radius (Ra Max) | 1 mm | |
| Fatigue Load Limit, Axial (Cua) | 14,600 N |
