Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications10 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Series | 200 | |
| Variant / construction | Radial Deep-Groove Ball | |
| Bore diameter | d | 29 mm |
| Outside diameter | D | 72 mm |
| Width | B | 25.001 mm |
| Basic dynamic load rating | C | 25.7 kN |
| Basic static load rating | C0 | 15.3 kN |
| Mass | ≈m | 0.38 kg |
| Sealing | Sealed | |
| Cage | Steel cage |
Calculation Factors6 parameters
| Parameter | Symbol | Value |
|---|---|---|
| K Factor | 0.00 | |
| Y1 Factor | 0.00 | |
| Y2 Factor | 0.00 | |
| Y0 Factor | 0.50 | |
| E Factor | 0.00 | |
| Cg Factor | 0.0352 |
Manufacturer Identity6 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Brand | Timken | |
| Material Number | 000000000100125620 | |
| World Assembly Part Number | 207KRR12 | |
| Upc | 0087796079809 | |
| Official Source System | CORE BP - DS DF | |
| Official Last Run | 2026-08-23T20:02:47.403 |
Product Identity4 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Type Description | Radial Deep-Groove Ball | |
| Construction | Single Row Deep Groove Ball Bearing | Imperial Series | 1.1260 in Bore | 2.8346 in OD | 0.9843 in Width | Double Sealed | Hex Bore | Steel Cage | C3 Clearance | ISO P0 Tolerance | |
| Number Of Rows | 1 | |
| Tapered Bore | N |
Technical Data10 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Overall Width | 0.000 mm | |
| Radial Rating | 28,500 N | |
| Axial Rating | 0 N | |
| Dynamic Rating C1 | 25,700 N | |
| Dynamic Rating C90 | 0 N | |
| Dynamic Axial Rating Ca90 | 0 N | |
| Dynamic Axial Rating Ca1 | 0 N | |
| Static Radial Rating C0 | 15,300 N | |
| Extended Dynamic Rating Ce | 28,500 N | |
| Static Axial Rating C0A | 0 N |
