Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications7 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Variant / construction | Deep groove ball bearings | |
| Bore diameter | d | 55.575 mm |
| Outside diameter | D | 100 mm |
| Width | B | 55.562 mm |
| Basic dynamic load rating | C | 43.4 kN |
| Basic static load rating | C0 | 29.2 kN |
| Mass | ≈m | 1.13 kg |
Dimensions3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore diameter | 55.575 mm | |
| Outside diameter | 100.0 mm | |
| Width | 55.562 mm |
Product identity4 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Official product category | Deep groove ball bearings | |
| Official taxonomy path | /products/rolling-bearings/ball-bearings/deep-groove-ball-bearings | |
| Available from SKF | Yes | |
| Remanufacturable | No |
Logistics1 parameter
| Parameter | Symbol | Value |
|---|---|---|
| Product net weight | 1.13 kg |
Performance2 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Basic dynamic load rating | 43.4 kN | |
| Basic static load rating | 29.2 kN |
Properties1 parameter
| Parameter | Symbol | Value |
|---|---|---|
| Indicative carbon footprint for new product | 4.2 kg CO 2 e |
