Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications9 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Variant / construction | Angular contact ball bearings | |
| Bore diameter | d | 16.1 mm |
| Outside diameter | D | 47 mm |
| Width | B | 24.6 mm |
| Basic dynamic load rating | C | 19.3 kN |
| Basic static load rating | C0 | 12.4 kN |
| Mass | ≈m | 0.233 kg |
| Sealing | Seal on both sides | |
| Lubricant | Grease |
Dimensions3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Bore diameter | 16.1 mm | |
| Outside diameter | 47.0 mm | |
| Width | 24.6 mm |
Product identity4 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Official product category | Angular contact ball bearings | |
| Official taxonomy path | /products/rolling-bearings/ball-bearings/angular-contact-ball-bearings/double-row-angular-contact-ball-bearings | |
| Available from SKF | Yes | |
| Remanufacturable | No |
Logistics1 parameter
| Parameter | Symbol | Value |
|---|---|---|
| Product net weight | 0.233 kg |
Performance2 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Basic dynamic load rating | 19.3 kN | |
| Basic static load rating | 12.4 kN |
Properties5 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Number of rows | 2 | |
| Sealing | Seal on both sides | |
| Sealing type | Contact | |
| Lubricant | Grease | |
| Indicative carbon footprint for new product | 0.86 kg CO 2 e |
