INA PHUE35

Take-up housing unit technical reference with manufacturer-sourced dimensions, characteristics and engineering resources.

Technical data available

Bore diameterd: 35 mm
Outside diameterD: 98 mm
Mass≈m: 1.9 kg
Length (L): 274 mm
Bore Diameter (D): 35 mm
Height Flange (H): 98 mm

Compare this model by brand →Check interchange requirements →

Use this page as a technical reference. Verify the current manufacturer specification and the complete application requirements before selection.

Technical data

Product specifications

Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.

Core specifications3 parameters

Core specifications
Parameter	Symbol	Value
Bore diameter	d	35 mm
Outside diameter	D	98 mm
Mass	≈m	1.9 kg

Manufacturer Identity2 parameters

Manufacturer Identity
Parameter	Symbol	Value
Schaeffler Product Code		1457748
Brand		INA

Product Identity1 parameter

Product Identity
Parameter	Symbol	Value
Short Description		Take-up housing unit

Technical Data3 parameters

Technical Data
Parameter	Symbol	Value
Length (L)		274 mm
Bore Diameter (D)		35 mm
Height Flange (H)		98 mm

Technical documents & data sheet

This product page is a BearingScope catalogue reference, not a manufacturer-certified drawing. Preserve the full brand and designation when comparing files.

Record identity: INA PHUE35
Document matching: Exact designation, assembly scope, revision and units must agree.

No verified redistributable CAD or manufacturer PDF is registered for this exact model. A catalogue image is not a dimensioned drawing. Missing technical files are not generated or replaced with unrelated models.

Look up another model or check drawing requirements →
