Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications12 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Series | NK18/16 | |
| Bore diameter | d | 18 mm |
| Outside diameter | D | 26 mm |
| Width | B | 16 mm |
| Basic dynamic load rating | C | 14.1 kN |
| Basic static load rating | C0 | 16.2 kN |
| Fatigue load limit | Pu | 3.05 kN |
| Reference speed | nref | 14400 r/min |
| Limiting speed | nG | 22100 r/min |
| Mass | ≈m | 0.025 kg |
| Minimum operating temperature | Tmin | -30 °C |
| Maximum operating temperature | Tmax | 120 °C |
Manufacturer Identity5 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Schaeffler Product Code | 382919 | |
| Brand | INA | |
| Base Type | NK18/16 | |
| Old Designation | ["NK18/16"] | |
| X Life Marking | XL |
Product Identity2 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Construction | Needle roller bearings NK, light series | |
| Short Description | Needle roller bearing |
Technical Data11 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Under Roller Diameter (Fw) | 18 mm | |
| Outside Diamater (D) | 26 mm | |
| Width, Outer Ring (C) | 16 mm | |
| Basic Dynamic Load Rating, Radial (Cr) | 14,100 N | |
| Basic Static Load Rating, Radial (C0R) | 16,200 N | |
| Operating Temperature Min. (Tmin) | -30 °C | |
| Operating Temperature Max. (Tmax) | 120 °C | |
| Limiting Speed (Limiting Spe) | 22,100 1/min | |
| Reference Speed (Nϑr) | 14,400 1/min | |
| Minimum Chamfer Dimension (Rmin) | 0.3 mm | |
| Fatigue Load Limit, Radial (Cur) | 3,050 N |
