Name: FAG C41/500-XL-K30-M1B-T52BW-C3
Brand: FAG
SKU: C41/500-XL-K30-M1B-T52BW-C3

Technical data

Product specifications

Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.

Core specifications13 parameters

Core specifications
Parameter	Symbol	Value
Series		C41/500
Bore diameter	d	500 mm
Outside diameter	D	830 mm
Width	B	325 mm
Basic dynamic load rating	C	10200 kN
Basic static load rating	C0	17800 kN
Fatigue load limit	Pu	1410 kN
Reference speed	nref	225 r/min
Limiting speed	nG	680 r/min
Mass	≈m	34.3 kg
Cage		M1B — solid brass cage, inner ring guided
Minimum operating temperature	Tmin	-30 °C
Maximum operating temperature	Tmax	200 °C

Product characteristics2 parameters

Product characteristics
Parameter	Symbol	Value
Bore type	K30	Tapered, taper 1:30
Cage	M1B	solid brass cage, inner ring guided

Main Dimensions & Performance Data9 parameters

Main Dimensions & Performance Data
Parameter	Symbol	Value
Bore diameter	d	500 mm19.685 in
Outside diameter	D	830 mm32.677 in
Width	B	325 mm12.795 in
Basic dynamic load rating, radial	Cr	10,200,000 N2,293,165.468 lbf
Basic static load rating, radial	C0r	17,800,000 N4,001,798.561 lbf
Fatigue load limit, radial	Cur	1,410,000 N316,996.403 lbf
Reference speed	nϑr	225 1/min
Limiting speed	nG	680 1/min
Mass	≈m	34.3 kg75.618 lbs

Mounting dimensions6 parameters

Mounting dimensions
Parameter	Symbol	Value
Minimum diameter shaft shoulder	da min	532 mm20.945 in
Maximum diameter shaft shoulder	da max	645 mm25.394 in
Minimum diameter of housing shoulder	Da min	709 mm27.913 in
Maximum diameter of housing shoulder	Da max	798 mm31.417 in
Maximum fillet radius	ra max	6 mm0.236 in
Minimum depth of free space Ca	Ca	7.28 mm0.287 in

Dimensions4 parameters

Dimensions
Parameter	Symbol	Value
Minimum chamfer dimension	rmin	7.5 mm0.295 in
Shoulder diameter of IR	d2	597.2 mm23.512 in
Shoulder diameter outer ring	D1	740.2 mm29.142 in
Axial displacement	S1	23 mm0.906 in

Temperature range2 parameters

Temperature range
Parameter	Symbol	Value
Operating temperature min.	Tmin	-30 °C-22 °F
Operating temperature max.	Tmax	200 °C392 °F

Calculation factors2 parameters

Calculation factors
Parameter	Symbol	Value
Operating clearance factor kδ	kδ	0.287
Tilting factor kφ	kφ	36.221

Capabilities & suitability6 parameters

Capabilities & suitability
Parameter	Symbol	Value
Radial load capacity		Yes
Suitable for grease lubrication		Yes
Suitable for oil lubrication		Yes
Unsealed design		Yes
Staticangularerrorandmisalignment		Yes
Dynamicangularerrorandmisalignment		Yes

Manufacturer Identity6 parameters

Product Identity2 parameters

Product Identity
Parameter	Symbol	Value
Construction		Toroidal roller bearing C41..-XL-K30-M1B
Short Description		Toroidal roller bearing

Technical Data22 parameters

Technical Data
Parameter	Symbol	Value
Bore Diameter (D)		500 mm
Outside Diameter (D)		830 mm
Width (B)		325 mm
Basic Dynamic Load Rating, Radial (Cr)		10,200,000 N
Basic Static Load Rating, Radial (C0R)		17,800,000 N
Operating Temperature Min. (Tmin)		-30 °C
Limiting Speed (Ng)		680 1/min
Operating Temperature Max. (Tmax)		200 °C
Reference Speed (Nϑr)		225 1/min
Minimum Diameter Of Housing Shoulder (Da Min)		709 mm
Axial Displacement (S1)		23 mm
Minimum Depth Of Free Space Ca (Ca)		7.28 mm
Operating Clearance Factor Kδ (Kδ)		0.287
Shoulder Diameter Of Ir (D2)		597.2 mm
Tilting Factor Kφ (Kφ)		36.221
Fatigue Load Limit, Radial (Cur)		1,410,000 N
Maximum Diameter Of Shaft Shoulder (Da Max)		645 mm
Minimum Diameter Shaft Shoulder (Da Min)		532 mm
Maximum Diameter Of Housing Shoulder (Da Max)		798 mm
Minimum Chamfer Dimension (Rmin)		7.5 mm
Maximum Fillet Radius (Ra Max)		6 mm
Shoulder Diameter Outer Ring (D1)		740.2 mm
