SKF
↗
C 4013-2CS5V/C3GEM9
Full complement carb toroidal roller bearing with integral sealing · 46 parameters
- Bore d
- 65 mm
- Outside D
- 100 mm
- Width B
- 35 mm
- Dynamic C
- 102 kN
- Static C0
- 173 kN
- Limit speed
- 150 r/min
Product category
14 PRODUCTS
Full complement carb toroidal roller bearing with integral sealing
Compare full complement carb toroidal roller bearing with integral sealing across the manufacturers currently loaded, then refine by designation and boundary dimensions.
Customer bearing search
Find a bearing model
Use a designation or exact metric dimensions. Advanced filters are available below.
Product taxonomy
Other bearing categories
Category counts include all currently loaded manufacturers. Brand counts are shown after entering a category.
View all categories →Guides, tables & tools
Browse all resources →Search a model number or a technical question. Product filters below apply to product records; the resource library has its own task and equipment filters.
Continue to product results ↓SKF↗
C 4022-2CS5V/C3GEM9
Full complement carb toroidal roller bearing with integral sealing · 48 parameters
- Bore d
- 110 mm
- Outside D
- 170 mm
- Width B
- 60 mm
- Dynamic C
- 415 kN
- Static C0
- 585 kN
- Limit speed
- 85 r/min
SKF↗
C 4024-2CS5V/C3GEM9
Full complement carb toroidal roller bearing with integral sealing · 48 parameters
- Bore d
- 120 mm
- Outside D
- 180 mm
- Width B
- 60 mm
- Dynamic C
- 430 kN
- Static C0
- 640 kN
- Limit speed
- 80 r/min
SKF↗
C 4026-2CS5V/C3GEM9
Full complement carb toroidal roller bearing with integral sealing · 48 parameters
- Bore d
- 130 mm
- Outside D
- 200 mm
- Width B
- 69 mm
- Dynamic C
- 550 kN
- Static C0
- 830 kN
- Limit speed
- 70 r/min
SKF↗
C 4030-2CS5V/C3GEM9
Full complement carb toroidal roller bearing with integral sealing · 48 parameters
- Bore d
- 150 mm
- Outside D
- 225 mm
- Width B
- 75 mm
- Dynamic C
- 585 kN
- Static C0
- 965 kN
- Limit speed
- 63 r/min
SKF↗
C 4032-2CS5V/C3GEM9
Full complement carb toroidal roller bearing with integral sealing · 48 parameters
- Bore d
- 160 mm
- Outside D
- 240 mm
- Width B
- 80 mm
- Dynamic C
- 830 kN
- Static C0
- 1290 kN
- Limit speed
- 60 r/min
SKF↗
C 4120-2CS5V/C3GEM9
Full complement carb toroidal roller bearing with integral sealing · 48 parameters
- Bore d
- 100 mm
- Outside D
- 165 mm
- Width B
- 65 mm
- Dynamic C
- 475 kN
- Static C0
- 655 kN
- Limit speed
- 90 r/min
SKF↗
C 4122-2CS5V/C3GEM9
Full complement carb toroidal roller bearing with integral sealing · 48 parameters
- Bore d
- 110 mm
- Outside D
- 180 mm
- Width B
- 69 mm
- Dynamic C
- 500 kN
- Static C0
- 710 kN
- Limit speed
- 80 r/min
SKF↗
C 4126-2CS5V/C3GEM9
Full complement carb toroidal roller bearing with integral sealing · 48 parameters
- Bore d
- 130 mm
- Outside D
- 210 mm
- Width B
- 80 mm
- Dynamic C
- 750 kN
- Static C0
- 1100 kN
- Limit speed
- 70 r/min
SKF↗
C 4128-2CS5V/C3GEM9
Full complement carb toroidal roller bearing with integral sealing · 48 parameters
- Bore d
- 140 mm
- Outside D
- 225 mm
- Width B
- 85 mm
- Dynamic C
- 780 kN
- Static C0
- 1200 kN
- Limit speed
- 63 r/min
SKF↗
C 5915-2CS5V/C4S3GEM9
Full complement carb toroidal roller bearing with integral sealing · 45 parameters
- Bore d
- 75 mm
- Outside D
- 105 mm
- Width B
- 40 mm
- Dynamic C
- 166 kN
- Static C0
- 232 kN
- Limit speed
- 130 r/min
SKF↗
C 5918-2CS5V/C3
Full complement carb toroidal roller bearing with integral sealing · 46 parameters
- Bore d
- 90 mm
- Outside D
- 125 mm
- Width B
- 46 mm
- Dynamic C
- 224 kN
- Static C0
- 400 kN
- Limit speed
- 110 r/min
SKF↗
C 6912-2NSV/C3
Full complement carb toroidal roller bearing with integral sealing · 44 parameters
- Bore d
- 60 mm
- Outside D
- 85 mm
- Width B
- 45 mm
- Dynamic C
- 190 kN
- Static C0
- 335 kN
SKF↗
C 6915-2CS5V/C3
Full complement carb toroidal roller bearing with integral sealing · 46 parameters
- Bore d
- 75 mm
- Outside D
- 105 mm
- Width B
- 54 mm
- Dynamic C
- 204 kN
- Static C0
- 325 kN
- Limit speed
- 140 r/min
