Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications10 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Series | EX26851 | |
| Variant / construction | Radial SRB | |
| Bore diameter | d | 64.175 mm |
| Outside diameter | D | 110 mm |
| Width | B | 57.4 mm |
| Basic dynamic load rating | C | 169 kN |
| Basic static load rating | C0 | 174 kN |
| Mass | ≈m | 1.18 kg |
| Sealing | Open | |
| Cage | Steel cage |
Calculation Factors6 parameters
| Parameter | Symbol | Value |
|---|---|---|
| K Factor | 0.00 | |
| Y1 Factor | 2.84 | |
| Y2 Factor | 4.23 | |
| Y0 Factor | 2.78 | |
| E Factor | 0.24 | |
| Cg Factor | 0.0547 |
Manufacturer Identity9 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Brand | Timken | |
| Material Number | 000000000190024382 | |
| World Assembly Part Number | SLV12 | |
| Inner Ring Part Number | 60ASDCV22 | |
| Outer Ring Part Number | 60ESDC22W33 | |
| Drawing Number | M941119 | |
| Upc | 0883450453486 | |
| Official Source System | CORE BP - DS DF | |
| Official Last Run | 2026-08-23T20:02:46.147 |
Product Identity4 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Type Description | Radial SRB | |
| Construction | Spherical Roller Bearing | Imperial Series | 2.5266 in Bore | 4.3307 in OD | 2.2600 in Width | Open | Tapered Bore | Steel Cage | C3 Clearance | |
| Number Of Rows | 2 | |
| Tapered Bore | Y |
Technical Data10 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Overall Width | 0.000 mm | |
| Radial Rating | 169,000 N | |
| Axial Rating | 0 N | |
| Dynamic Rating C1 | 169,000 N | |
| Dynamic Rating C90 | 0 N | |
| Dynamic Axial Rating Ca90 | 0 N | |
| Dynamic Axial Rating Ca1 | 0 N | |
| Static Radial Rating C0 | 174,000 N | |
| Extended Dynamic Rating Ce | 0 N | |
| Static Axial Rating C0A | 0 N |
