Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications8 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Series | EX26855 | |
| Variant / construction | Radial SRB | |
| Bore diameter | d | 44.45 mm |
| Outside diameter | D | 85 mm |
| Width | B | 73.03 mm |
| Basic dynamic load rating | C | 109 kN |
| Basic static load rating | C0 | 108 kN |
| Mass | ≈m | 1.02 kg |
Calculation Factors6 parameters
| Parameter | Symbol | Value |
|---|---|---|
| K Factor | 0.00 | |
| Y1 Factor | 2.64 | |
| Y2 Factor | 3.93 | |
| Y0 Factor | 2.58 | |
| E Factor | 0.26 | |
| Cg Factor | 0.0459 |
Manufacturer Identity9 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Brand | Timken | |
| Material Number | 000000000190025972 | |
| World Assembly Part Number | SLA09-112 | |
| Inner Ring Part Number | 45ASDCA22-112 | |
| Outer Ring Part Number | 45ESDC22W33 | |
| Drawing Number | M942593 | |
| Upc | 0883450453776 | |
| Official Source System | CORE BP - DS DF | |
| Official Last Run | 2026-08-23T20:02:48.587 |
Product Identity3 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Type Description | Radial SRB | |
| Number Of Rows | 2 | |
| Tapered Bore | N |
Technical Data10 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Overall Width | 0.000 mm | |
| Radial Rating | 109,000 N | |
| Axial Rating | 0 N | |
| Dynamic Rating C1 | 109,000 N | |
| Dynamic Rating C90 | 0 N | |
| Dynamic Axial Rating Ca90 | 0 N | |
| Dynamic Axial Rating Ca1 | 0 N | |
| Static Radial Rating C0 | 108,000 N | |
| Extended Dynamic Rating Ce | 0 N | |
| Static Axial Rating C0A | 0 N |
