KOYO PU406222RR9DY1

Automotive bearings technical reference with manufacturer-sourced dimensions, characteristics and engineering resources.

Technical data available

Outside diameterD: 62 mm
WidthB: 43.4 mm
Stockno.: 77033
D: 62 mm
B: 43.4 mm
D1: 31 mm

Compare this model by brand →Check interchange requirements →

Use this page as a technical reference. Verify the current manufacturer specification and the complete application requirements before selection.

Technical data

Product specifications

Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.

Core specifications3 parameters

Core specifications
Parameter	Symbol	Value
Variant / construction		Tensioner bearings
Outside diameter	D	62 mm
Width	B	43.4 mm

Manufacturer Identity2 parameters

Manufacturer Identity
Parameter	Symbol	Value
Brand		KOYO
Official Class Key		200-050-000

Classification2 parameters

Classification
Parameter	Symbol	Value
Official Category Path		Automotive bearings - Tensioner bearings
Official Classification 1		Automotive bearings / Tensioner bearings

Technical Data6 parameters

Technical Data
Parameter	Symbol	Value
Stockno.		77033
D		62 mm
B		43.4 mm
D1		31 mm
B1		35.1 mm
Reference Part Number		トヨタ (TOYOTA) 13505-05010, 13505-54020, 13505-54021

Technical documents & data sheet

This product page is a BearingScope catalogue reference, not a manufacturer-certified drawing. Preserve the full brand and designation when comparing files.

Record identity: KOYO PU406222RR9DY1
Document matching: Exact designation, assembly scope, revision and units must agree.

No verified redistributable CAD or manufacturer PDF is registered for this exact model. A catalogue image is not a dimensioned drawing. Missing technical files are not generated or replaced with unrelated models.
