KOYO DG3265A2RD1DCS39+Z

Automotive bearings technical reference with manufacturer-sourced dimensions, characteristics and engineering resources.

Technical data available

Bore diameterd: 24 mm
Outside diameterD: 65 mm
WidthB: 19 mm
Stockno.: 70041
d: 24 mm
B: 19 mm

Compare this model by brand →Check interchange requirements →

Use this page as a technical reference. Verify the current manufacturer specification and the complete application requirements before selection.

Technical data

Product specifications

Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.

Core specifications4 parameters

Core specifications
Parameter	Symbol	Value
Variant / construction		Tensioner bearings
Bore diameter	d	24 mm
Outside diameter	D	65 mm
Width	B	19 mm

Manufacturer Identity2 parameters

Manufacturer Identity
Parameter	Symbol	Value
Brand		KOYO
Official Class Key		200-050-000

Classification2 parameters

Classification
Parameter	Symbol	Value
Official Category Path		Automotive bearings - Tensioner bearings
Official Classification 1		Automotive bearings / Tensioner bearings

Technical Data5 parameters

Technical Data
Parameter	Symbol	Value
Stockno.		70041
d		24 mm
D		65 mm
B		19 mm
Reference Part Number		ホンダ (HONDA) 14510-PH7-003, 14510-PH7-004

Technical documents & data sheet

This product page is a BearingScope catalogue reference, not a manufacturer-certified drawing. Preserve the full brand and designation when comparing files.

Record identity: KOYO DG3265A2RD1DCS39+Z
Document matching: Exact designation, assembly scope, revision and units must agree.

No verified redistributable CAD or manufacturer PDF is registered for this exact model. A catalogue image is not a dimensioned drawing. Missing technical files are not generated or replaced with unrelated models.

Look up another model or check drawing requirements →
