Technical data
Product specifications
Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.
Core specifications8 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Series | GVK100 | |
| Outside diameter | D | 80 mm |
| Width | B | 36.5 mm |
| Basic dynamic load rating | C | 32.5 kN |
| Basic static load rating | C0 | 19.8 kN |
| Mass | ≈m | 0.697 kg |
| Minimum operating temperature | Tmin | -20 °C |
| Maximum operating temperature | Tmax | 100 °C |
Manufacturer Identity4 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Schaeffler Product Code | 357205 | |
| Brand | INA | |
| Base Type | GVK100 | |
| X Life Marking | n.r. |
Product Identity2 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Construction | Plummer block housing unit GVK..-208-KTT-B-AS2/V, RIBB sheet metal PB | |
| Short Description | Self-aligning deep groove ball bearings |
Technical Data18 parameters
| Parameter | Symbol | Value |
|---|---|---|
| Outside Diameter (Dsp) | 80 mm | |
| Width, Inner Ring (B) | 36.5 mm | |
| Basic Dynamic Load Rating, Radial (Cr) | 32,500 N | |
| Basic Static Load Rating, Radial (C0R) | 19,800 N | |
| Width Across Flats Lower Tolerance (Width Across) | 0.6 mm | |
| Operating Temperature Min. (Tmin) | -20 °C | |
| Operating Temperature Max. (Tmax) | 100 °C | |
| Width, Outer Ring (C) | 21 mm | |
| Width Across Flats (Inch) (D) | 1 in | |
| Width Across Flats Upper Tolerance (Width Across) | 0.9 mm | |
| Calculation Factor (F0) | 13.6 | |
| Distance To Lubrication Hole (Ca) | 6.4 mm | |
| Maximum Distance Hexagonal Bore (F) | 35.4 mm | |
| Radius Hexagonal Bore (R) | 2.5 mm | |
| Sealing Total Width (C2) | 28.1 mm | |
| Outside Diameter Seal (D1) | 68.3 mm | |
| Width Of Flats (D) | 25.4 mm | |
| Shoulder Diameter Inner Ring (D1) | 52.3 mm |
