INA AB.LFR5301

Wiper technical reference with manufacturer-sourced dimensions, characteristics and engineering resources.

Technical data available

Mass≈m: 0.026 kg
Length Tolerance High L Tol Tec (Ltol): 0.1 mm
Length Of Carriage (L): 76 mm

Compare this model by brand →Check interchange requirements →

Use this page as a technical reference. Verify the current manufacturer specification and the complete application requirements before selection.

Technical data

Product specifications

Metric and imperial values are paired where the manufacturer provides both. Expand a section to review its parameters.

Core specifications2 parameters

Core specifications
Parameter	Symbol	Value
Series		AB.LFR5301..
Mass	≈m	0.026 kg

Manufacturer Identity3 parameters

Manufacturer Identity
Parameter	Symbol	Value
Schaeffler Product Code		834571
Brand		INA
Base Type		AB.LFR5301..

Product Identity2 parameters

Product Identity
Parameter	Symbol	Value
Construction		Lubrication and wiper units for LFR
Short Description		Wiper

Technical Data2 parameters

Technical Data
Parameter	Symbol	Value
Length Tolerance High L Tol Tec (Ltol)		0.1 mm
Length Of Carriage (L)		76 mm

Technical documents & data sheet

This product page is a BearingScope catalogue reference, not a manufacturer-certified drawing. Preserve the full brand and designation when comparing files.

Record identity: INA AB.LFR5301
Document matching: Exact designation, assembly scope, revision and units must agree.

No verified redistributable CAD or manufacturer PDF is registered for this exact model. A catalogue image is not a dimensioned drawing. Missing technical files are not generated or replaced with unrelated models.
